Customized Black Rubber Ep Nylon Polyester Material for Crusher Mining Conveyor Belt Wear Resistant Sand Convey Stone Quarry

Overview
Product Description
Product Parameters
Company Profile
Certifications
FAQ

Overview

Basic Info.

Inside Material	Fabric
Feature	Oil-Resistant, Acid And Alkali Resistant, Tear-Resistant, Heat-Resistant, Cold-Resistant, Wear-Resistant
Tensile Strength	Strong
Transport Package	Wave Bags
Specification	600-2500mm width
Trademark	Huadu
Origin	China
Production Capacity	2000m Per Day

Product Description

huadu conveyor belt are designed to the highest standards ,to transport all types of bulk material,including mining,
stone and earth handling , building industries,recycling, steel processing , wood, paper and pulp.

Product Description

Property :
Resistant to impact

√ High strength

√ Low elongation

√ High resistant to abrasion

√ Suitable for long distance,large loading capacity and high speed transportation

Manufacturing standards GB/T 7984 DIN 22102 JISK 6322 AS 1332-2000 SANS 1173:2005 BS 490

Conveyor Belt Properties Rubber conveyor belts have the following properties depending on the environment in which they are used:· Cold Resistance· Heat Resistance· Anti-static· Fire Resistance· Oil Resistance· Abrasion Resistance

Product Parameters

Cover Rubber grade

8MPA,10MPA,12MPA, 15MPA18MPA,20MPA, 24MPA,26MPA

DIN-X,Y,W
RMA-1,RMA-2
N17,M24

Belt width (mm)

500,600.650,700,800, 1000,1200,1400,1500,1800,2000, 2200,2500,3000

18",20",24", 30",36",40", 42",48",60", 72",78",86", 94"

Tensile strength

EP315/3,EP400/3,EP500/3, EP600/3,EP400/4,EP500/4, EP600/4,EP500/5,EP1000/5, EP1250/5,EP600/6,EP1200/6

330PIW, 440PIW

Top+Bottom thickness

3+1.5, 4+2, 4+1.5, 4+3, 5+1.5

3/16"+1/16", 1/4"+1/16"

Belt thickness

3mm,4mm,5mm,6mm,7mm,8mm,9mm,10mm,12mm,15mm,20mm,25mm

Belt length

10m,20m,50m,100m,200m,250m,300m,500m

Belt edge type

Moulded(sealed) edge or cut edge

Company Profile Certifications FAQ

Q1.What's the order process?

1)Inquiry---provide us all clear requirements (total qty and package details). 2)Quotation---official quotation from with all clear specifications from our professional team. 3)Marking Sample --- confirm all quotation details and the final sample.
4)Production---mass production. 5)Shipping---by sea or by air.
